PANDUIT HD Flex™ OS2 Fibre Optic Breakout Cassette | Selector

HD Flex™ Fibre Optic Breakout Cassettes

Available in a range of formats:

·         1 x 8f rear MPO to 4 x front LC

·         3 x 8f rear MPO to 12 x front LC

·         1 x 24f rear MPO to 12 x front LC

Features

·         Compatible with HD Flex™ Rack Mount Enclosures, Panels, and Zero RU Brackets

·         LC adapters include integral shutters for dust protection and VFL light identification

·         Low insertion loss of 0.5dB per optimised cassette, 0.35dB for ultra cassette, and 0.75dB for standard singlemode cassette

·         Return loss >26dB (multimode) and >55dB (singlemode).

·         Adapter housing colours follow ANSI/TIA-568.3-D suggested colour identification scheme

·         Cassettes accessible from the front or back to streamline installation and migration from 10G to 40G/100G and beyond

·         Performance test data provided with each cassette

·         Lifetime traceability of test data to a QC numbers on each fibre cassette
