Fluke Networks SimpliFiber® Pro Optical Power Meter - SFSINGLEMODESOURCE

Name: Fluke Networks SimpliFiber® Pro Optical Power Meter - SFSINGLEMODESOURCE
Brand: Fluke Networks
SKU: SFSINGLEMODESOURCE
Availability: InStock

SKU SFSINGLEMODESOURCE

by Fluke Networks

Fast delivery from stock MOQ's apply on some items

Need some help? Call us on 01403 754233

Description

Fluke Networks singlemode laser light source for the SimpliFiber® series.

Check the Part Number and Specifications tab for full details.

Got any questions? Call 01403 756588 during office hours to speak to a team member.

Features

SimpliFiber Pro Kit Configurations
Fiber Inspection
Fiber Cleaning
Results Management
Verify and Locate Faults
Unique Capabilities

Specifications

Environmental Specifications
Operating Temperature	-10º C to 50º C
Storage Temperature	-20º C to 50º C
Operating Humidity	95% (10º C to 35º C) Non-Condensing 75% (35º C to 40º C) Non-Condensing Uncontrolled <10º C
EMI, RFI, EMC	Standards compliant¹

¹ Conforms to relevant European Union directives; Conforms to relevant Australian standards; Listed by the Canadian Standards Association; Complies with 21CFR.1040.10,11, and EN60825-1, 2:2007 (Class 1, Hazard Level 1)

Singlemode Optical Source
Emitter Type	1310 nm/1550 nm: dual FP laser 1490 nm/1625 nm: dual DFB laser
Central wavelength	1310 nm: ±20 nm 1550 nm: ±30 nm 1490 nm: ±3 nm 1625 nm: ±5 nm
Wavelength Accuracy	1310 nm: +/- 20 nm 1550 nm: +/- 30 nm
Spectral width (RMS)	1310 nm: 2 nm (maximum) 1550 nm: 3 nm (maximum) 1490 nm/1625 nm: 1 nm (maximum)
Minimum output power	1310/1550 nm ≥ -7dBm (typical) 1490 nm/1625 nm: ≥ -3 dBm (typical)
Power Output Stability¹	±0.25 dB over 8 hours
Auto Dual-Wavelength Switching	Yes. Can be enabled or disabled by user.
Optical Connector	Fixed SC
Launch Condition	9/125 μm fibre
FindFiber Code Generation	1310/1550 source is fixed at ID 2 1490 nm/1625 nm is fixed at ID 3.
Modes	CW, 2 kHz modulated, Auto-wavelength
Power Requirement	2 AA Alkaline batteries
Battery Life²	30 hrs (typical)
Automatic Power Off	30 minutes (can be enabled or disabled by user)
Low Battery Warning	LED blinks.
Size (L x W x H)	5.6 in x 3.2 in x 1.6 in (14.2 cm x 8.1 cm x 4.1cm)
Weight	9.8 oz (278 grams)

¹ 23° C ± 2° C, after 5 minutes warm-up time
² In auto-wavelength mode, battery life depends on the condition and type of batteries used. Fluke Networks recommends alkaline batteries.
