Fluke LinkIQ™ Duo Kit + 1G/10G Fibre Kit
Fast delivery from stock MOQ's apply on some items
Need some help? Call us on 01403 754233
LIQ-DUO-KIT-FMC-H6EU combines the LIQ-200 Duo Kit and Fibre Kit,1G/10G
Provides the perfect combo to cover Copper, Fibre and Wireless Network Testing.
Kit Includes LIQ-200 Kit with LIQ-200 Duo, remote ID’s, IntelliTone Probe and the Fibre Kit 1G/10G.
LIQ-200 Duo Kit
The LinkIQ™ Cable+Network Tester is the testing solution to verify cable performance up to 10 Gb/s and solve network connectivity problems. The LinkIQ tester validates cable performance using frequency-based measurements and a wire map of the cable under test. It also performs ping tests to verify connectivity and nearest switch diagnostics to identify key network issues and validate switch configuration - eliminating the need for another device. The LinkIQ Duo model adds Wi-Fi analysis to Wi-Fi 6E (where approved), including networks, channels, and access points plus warning of common configuration issues. Additional features include Analog and Digital Toning, Port Blink, Remote Office Locators, and the ability to manage results via LinkWare™ PC.
Fibre Kit 1G/10G
Use the Fluke Networks Fibre Media Converter (FMC) Kit to understand and debug the fibre port connections by determining application, switch name, port
name and VLAN and verifying connectivity using IP ping. The FMC includes the Media Converters, SFPs, fibre optic cords and RJ45 cable to connect with the
LinkIQ tester to troubleshoot network connectivity.
When testing a connection through the FMC, the “Network” test provides results that can tell you if you have an Ethernet connection to the device at the far end (typically a switch) and if you can send IP traffic to targets at the far end.
Connects to 1 Gb/s (1000BASE-SX, 1000BASE-LX) and 10 Gb/s (10GBASE-SR, 10GBASE-LR) fibre Ethernet ports through a media converter and SFP (1G/10G) using single-mode or multimode optic fibre cables.
Fibre optic network testing features including: IPv4 and v6 ping, nearest switch diagnostics (IP address, name, port / VLAN number).
Power bank for portable operation.
Includes single carrying case for LinkIQ/ LinkIQ Duo tester, media converters (1G and 10G), battery pack, fibre optic patch cords (single-mode and multimode), RJ45 connector cable, SFPs (single-mode and multimode) and accessories.
